Standard Type PDS Series
| Product | Type | Free Air Delivery [m3/min] |
Rated Operating Pressure [MPa] |
Engine Make/Model |
Designated emissions Regulation |
|---|---|---|---|---|---|
| PDS80S-5C5 | Box | 2.3 | 0.7 | KUBOTA D902-K3A |
JPN Stage 3 |
| PDS100S-5C5 | Box | 2.8 | 0.7 | KUBOTA D1105-K3A |
JPN Stage 3 |
| PDS130S-5C3 | Box | 3.7 | 0.69 | YANMAR 3TNV88-BDHK |
JPN Stage 3 |
| PDS185S-6C2 | Trailer | 5.2 | 0.69 | YANMAR 4TNV88-BXDHKS1 |
US Tier 3 |
| PDS185S-5C5 | Box | 5.2 | 0.7 | YANMAR 4TNV88-BXDHKSR |
JPN Stage 3 |
| PDS185S-7C5 | Oil Fence / Box | 5.2 | 0.7 | YANMAR 4TNV88-BXDHKSR |
JPN Stage 3 |
| PDS265S-4C3 | Trailer | 7.5 | 0.69 | YANMAR KDP-4TNV98T |
JPN Stage 3 |
| PDS265S-4B2 | Trailer | 7.5 | 0.69 | YANMAR 4TNV98T-NHK |
JPN stage 2 |
| PDS265S-5C3 | Box | 7.5 | 0.69 | YANMAR KDP-4TNV98T |
JPN Stage 3 |
| PDS265S-5B2 | Box | 7.5 | 0.69 | YANMAR 4TNV98T-NHK |
JPN Stage 2 |
| PDS390S-4C1 | Trailer | 11.0 | 0.69 | ISUZU CI-4JJ1X |
JPN Stage 3 |
| PDS390S-5C1 | Box | 11.0 | 0.69 | ISUZU CI-4JJ1X |
JPN Stage 3 |
| PDS400S-6B5 | Trailer | 11.3 | 0.7 | KUBOTA V3800DI-TI-E2B-COHE1 |
Tier 2 |
| PDS655S-4B2 | Trailer | 18.5 | 0.7 | HINO J08C-V |
JPN Stage 2 |
| PDS670S-4C5 | Trailer | 19.0 | 0.7 | ISUZU AI-4HK1X |
JPN Stage 3 |
| PDS750S-4B1 | Trailer | 21.2 | 0.7 | HINO J08C-UT |
JPN Stage 2 |
